Welding Positions: 4 Main Types - Weld Guru

Vertical Position (3F or 3G)

In vertical position welding, the axis of the weld is approximately vertical.

When welding is done on a vertical surface, the molten metal has a tendency to run downward and pile up.

Fillet weld on a lap joint in the vertical position

The flow of metal can be controlled by pointing the flame upward at a 45 degree angle to the plate, and holding the rod between the flame and the molten puddle (see above).

The manipulation of the torch and the filler rod keeps the metal from sagging or falling and ensures good penetration and fusion at the joint.

Both the torch and the welding rod should be oscillated to deposit a uniform bead. The welding rod should be held slightly above the centerline of the joint, and the welding flame should sweep the molten metal across the joint to distribute it evenly.

Vertical Position Butt Joint

Butt joints welded in the vertical position should be prepared for welding in the same manner as that required for welding in the flat position.

Overhead Position (4F or 4G)

Overhead welding is performed from the underside of a joint.

In overhead welding, the metal deposited tends to drop or sag on the plate, causing the bead to have a high crown.

To overcome this difficulty, the molten puddle should be kept small, and enough filler metal should be added to obtain good fusion with some reinforcement at the bead. If the puddle becomes too large, the flame should be removed for an instant to permit the weld metal to freeze.

When welding light sheets, the puddle size can be controlled by applying the heat equally to the base metal and filler rod.

Fillet weld on a lap joint in the overhead position

The flame should be directed so as to melt both edges of the joint. Sufficient filler metal should be added to maintain an adequate puddle with enough reinforcement.

The welding flame should support the molten metal and small welding avoid burning done from one distribute it along the joint.

Only a small puddle is required, so a rod should be used. Care should be taken to control the heat to through the plates.

This is particularly important when welding is side only.

Overhead Butt Joint

Positions for Pipe Welding

Pipe welds are made under many different requirements and in different welding situations. The welding position is dictated by the job.

In general, the position is fixed, but in some cases can be rolled for flat-position work. Positions and procedures for welding pipe are outlined below.

Pipe Inclined Fixed (45 degrees + 5 degrees) and Not Rotated During Welding

Horizontal Pipe Rolled Weld

Align the joint and tack weld or hold in position with steel bridge clamps with the pipe mounted on suitable rollers. Start welding at point C (figure below) progressing upward to point B. When point B is reached, rotate the pipe clockwise until the stopping point of the weld is at point C and again weld upward to point B. When the pipe is being rotated, the torch should be held between points B and C and the pipe rotated past it.

Diagram of Tac Welded Pipe on Rollers

The position of the torch at point A is similar to that for a vertical weld. As point B is approached, the weld assumes a nearly flat position and the angles of application of the torch and rod are altered slightly to compensate for this change.

The weld should be stopped just before the root of the starting point so that a small opening remains. The starting point is then reheated, so that the area surrounding the junction point is at a uniform temperature. This will ensure a complete fusion of the advancing weld with the starting point.

If the sidewall of the pipe is more than 1/4 in. (0.64 cm) in thickness, a multi-pass weld should be made.

Horizontal Pipe Fixed Position Weld

After tack welding, the pipe is set up so that the tack welds are oriented approximately as shown below. After welding has been started, the pipe must not be moved in any direction.

Diagram of Horizontal Pipe Weld with Uphand Method

When welding in the horizontal fixed position, the pipe is welded in four steps as described below.

  1. Starting at the bottom or 6 o’clock position, weld upward to the 3 o’clock position.
  2. Starting back at the bottom, weld upward to the 9 o’clock position.
  3. Starting back at the 3 o’clock position, weld to the top.
  4. Starting back at the 9 o’clock position, weld upward to the top overlapping the bead.

When welding downward, the weld is made in two stages. Start at the top (see below) and work down one side to the bottom, then return to the top and work down the other side to join with the previous weld at the bottom. The welding downward method is particularly effective with arc welding, since the higher temperature of the electric arc makes possible the use of greater welding speeds. With arc welding, the speed is approximately three times that of the upward welding method.

Horizontal Pipe Weld with Downhand Method

Welding by the backhand method is used for joints in low carbon or low alloy steel piping that can be rolled or are in a horizontal position. One pass is used for wall thicknesses not exceeding 3/8 in. (0.95 cm), two passes for wall thicknesses 3/8 to 5/8 in. (0.95 to 1.59 cm), three passes for wall thicknesses 5/8 to 7/8 in. (1.59 to 2.22 cm), and four passes for wall thicknesses 7/8 to 1-1/8 in. (2.22 to 2.87 cm).

Vertical Pipe Fixed Position Weld

Pipe in this position, wherein the joint is horizontal, is most frequently welded by the backhand method. The weld is started at the tack and carried continuously around the pipe.

Vertical Pipe Fixed Position Weld with Backhand Method

Multipass Arc Welding

Root Beads

If a lineup clamp is used, the root bead (see below) is started at the bottom of the groove while the clamp is in position. When no backing ring is used, care should be taken to build up a slight bead on the inside of the pipe. If a backing ring is used, the root bead should be carefully fused to it. As much root bead as the bars of the lineup clamp will permit should be applied before the clamp is removed. Complete the bead after the clamp is removed.

Deposition of Root, Filler and Finish Weld Beads

Filler Beads

Care should be taken that the filler beads (see diagram view B above) are fused into the root bead, in order to remove any undercut causal by the deposition of the root bead. One or more filler beads around the pipe usually will be required.

Finish Beads

The finish beads (see diagram view C above) are applied over the filler beads to complete the joint. Usually, this is a weave bead about 5/8 in. (1.59 cm) wide and approximately 1/16 in. (0.16 cm) above the outside surface of the pipe when complete. The finished weld is shown in view D above.

Aluminum Pipe Welding

For aluminum pipe, special joint details have been developed and are normally associated with combination-type procedures. A backing ring is not used in most cases. The rectangular backing ring is rarely used when fluids are transmitted through the piping system. It may be used for structural applications in which pipe and tubular members are used to transmit loads rather than materials.
